Cr10Ni90 NiCr Alloy Heating Resistance Wire delivers exceptional high-temperature resistance, making it ideal for precision heating elements and durable industrial applications. Crafted with an 90% nickel and 10% chromium alloy composition, it provides excellent oxidation resistance and extended service life in extreme environments, serving as a reliable choice for manufacturing resistance components and thermal processing systems.
Cr10Ni90/Cr20Ni80/Cr30Ni70/Cr15Ni60/Cr20Ni35/Cr20Ni30
DLX
Bright
Customized Size
8.4g/cm3
637-784Mpa
ISO9001/ CE/ROHS
5kg
1300-1390°C
5-20 Days
chemical,petroleum
Product Description
Engineered for superior high-resistance applications in heating elements and industrial furnaces, Cr10Ni90 NiCr Alloy Heating Resistance Wire delivers reliable performance up to 1250°C. This austenitic alloy with 10% chromium content ensures extended service life in furnace applications, immune to "green rot" and compatible with both reducing/oxidizing atmospheres.
Featuring high resistivity (1.18μΩ·m), exceptional oxidation resistance, and cold-forming capability with low thermal expansion (14.2×10⁻⁶/℃), it is the optimal solution for industrial furnace windings, precision resistance coils, and high-temperature heating systems.
Specification
Shape | Size(mm) |
| Wire | 0.05-7.5 |
| Rod | 8-50 |
| Ribbon | (0.05-0.35)*(0.5-6.0) |
| Strip | (0.5-2.5)*(5-180) |
| Performance material | Cr10Ni90 | Cr20Ni80 | Cr30Ni70 | Cr15Ni60 | Cr20Ni35 | Cr20Ni30 | |
| composition | Ni | 90 | Rest | Rest | 55.0～61.0 | 34.0～37.0 | 30.0～34.0 |
| Cr | 10 | 20.0～23.0 | 28.0～31.0 | 15.0～18.0 | 18.0～21.0 | 18.0～21.0 | |
| Fe | -- | ≤1.0 | ≤1.0 | Rest | Rest | Rest | |
| Maximum temperature℃ | 1300 | 1200 | 1250 | 1150 | 1100 | 1100 | |
| Meltiing point ℃ | 1400 | 1400 | 1380 | 1390 | 1390 | 1390 | |
| Density(g/cm3) | 8.7 | 8.4 | 8.1 | 8.2 | 7.9 | 7.9 | |
| Resistivity | -- | 1.09±0.05 | 1.18±0.05 | 1.12±0.05 | 1.00±0.05 | 1.04±0.05 | |
| Elongation at rupture | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 | ≥20 | |
| Specific heat J/g.℃ | -- | 0.44 | 0.461 | 0.494 | 0.5 | 0.5 | |
| Thermal conductivity KJ/m.h℃ | -- | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 | |
| Coefficient of lines expansion | -- | 18 | 17 | 17 | 19 | 19 | |
| Micrographic structure | -- | Austenite | Austenite | Austenite | Austenite | Austenite | |
| Magnetic properties | -- | Nonmagnetic | Nonmagnetic | Nonmagnetic | Nonmagnetic | Nonmagnetic | |
Application Field
Cr20Ni80 Nickel Chromium Wire is widely used in industrial furnaces, precision resistors, and heating elements for appliances like ovens and kilns. Its high resistance and corrosion resistance make it ideal for harsh environments, including chemical processing and aerospace applications, ensuring reliable high-temperature performance.
